1. General Machinery Industry: Flanges, gear blanks, pulleys, couplings, motor end covers, bearing housings
2. Construction & Mining Machinery: Excavator hubs, track rollers, hydraulic cylinder bases, crusher rotors, wear-resistant bushings
3. Automotive & Rail Transit: Automotive wheels, aluminum rims, brake drums, brake discs, flywheels, high-speed train brake discs, bogie flanges, railway wheels
4. Energy Equipment (Wind / Hydro / Nuclear Power): Wind turbine flanges, turbine runner bodies, nuclear reactor heads, sealing rings
5. Petrochemical & Explosion-Proof Equipment: Rod connectors, wellhead flanges, valve bodies, explosion-proof motor end covers, sealing shaft sleeves
6. Aerospace & Lightweight Equipment: Aircraft landing gear hubs, engine turbine disk blanks, casings, carbon fiber flanges / shaft sleeves
7. Mold Manufacturing: Plastic mold cores / cavities, bottle molds, tire mold pattern rings, die-casting mold inserts
1. FANUC 0i-TF CNC system;
2. Single-acting, high-clamping-force 4-jaw chuck;
3. Two-stage gear-driven spindle gearbox;
4. Square ram / Hydraulic servo vertical turret (4T / 5T / 6T);
5. Hydraulic system;
6. Coolant system;
7. Automatic lubrication system;
8. Electrical cabinet air conditioner;
9. Chain-type chip conveyor;
10. External protective sheet metal
1. Siemens 828D / GSK GSK988TA CNC system;
2. ATC tool magazine (10T, 12T, 16T);
3. High-pressure through-spindle coolant;
4. Automatic door;
5. Grinding capability;
6. Paper belt filter;
7. Oil-water separator;
8. Oil mist collector;
9. Tool breakage detection system;
10. Workpiece probing system;
11. X/Z-axis closed-loop linear scales
1. Table diameter: 1000 mm;
2. Max. turning diameter: Φ1250 mm;
3. Max. turning height: 1000 mm;
4. Max. workpiece weight: 5000 kg;
5. Spindle power/speed: 37/45 kW @ 300 rpm;
6. Spindle torque: 8000 Nm;
7. ATC tool magazine: 12T;
8. Machine weight: 18000 kg
High coaxiality control for large components; nuclear components require non-damaging machining compliant with pressure standards.
Capable of machining corrosion-resistant materials (e.g., stainless steel, titanium alloys); suitable for dust-proof and explosion-proof workshop environments.
Same as ETL125ATC
1. FANUC 0i-TF CNC system;
2. Single-acting, high-clamping-force 4-jaw chuck;
3. Two-stage gear-driven spindle gearbox;
4. Square ram / Hydraulic servo vertical turret (4T / 5T / 6T);
5. Hydraulic system;
6. Coolant system;
7. Automatic lubrication system;
8. Electrical cabinet air conditioner;
9. Chain-type chip conveyor;
10. External protective sheet metal;
11. C-axis (CF-axis) – drilling & milling function
Same as ETL125ATC optional configuration
1. Table diameter: 1000 mm;
2. Max. turning diameter: Φ1250 mm;
3. Max. turning height: 1000 mm;
4. Max. workpiece weight: 5000 kg;
5. Spindle power/speed: 37/45 kW @ 300 rpm;
6. Spindle torque: 8000 Nm;
7. ATC tool magazine: 16T;
8. C-axis (CF-axis) – milling function;
9. Machine weight: 19000 kg
Includes secondary milling spindle
High coaxiality control for large components; nuclear components require non-damaging machining compliant with pressure standards.
Capable of machining corrosion-resistant materials (e.g., stainless steel, titanium alloys); suitable for dust-proof and explosion-proof workshop environments.
Same as ETL125ATC
Same as ETL125ATC standard configuration
Same as ETL125ATC optional configuration
1. Table diameter: 1400 mm;
2. Max. turning diameter: Φ1600 mm;
3. Max. turning height: 1200 mm;
4. Max. workpiece weight: 8000 kg;
5. Spindle power/speed: 37/45 kW @ 300 rpm;
6. Spindle torque: 12000 Nm;
7. ATC tool magazine: 12T;
8. C-axis (CF-axis) – milling function;
9. Machine weight: 22000 kg
High coaxiality control for large components; nuclear components require non-damaging machining compliant with pressure standards.
Capable of machining corrosion-resistant materials (e.g., stainless steel, titanium alloys); suitable for dust-proof and explosion-proof workshop environments.
Same as ETL125ATC
Same as ETL125ATC+C standard configuration
Same as ETL125ATC optional configuration
1. Table diameter: 1400 mm;
2. Max. turning diameter: Φ1600 mm;
3. Max. turning height: 1200 mm;
4. Max. workpiece weight: 8000 kg;
5. Spindle power/speed: 37/45 kW @ 300 rpm;
6. Spindle torque: 12000 Nm;
7. ATC tool magazine: 16T;
8. C-axis (CF-axis) – milling function;
9. Machine weight: 23000 kg
Includes secondary milling spindle
High coaxiality control for large components; nuclear components require non-damaging machining compliant with pressure standards.
Capable of machining corrosion-resistant materials (e.g., stainless steel, titanium alloys); suitable for dust-proof and explosion-proof workshop environments.
Same as ETL125ATC
Same as ETL125ATC standard configuration
Same as ETL125ATC optional configuration
1. Table diameter: 1800 mm;
2. Max. turning diameter: Φ2000 mm;
3. Max. turning height: 1400 mm;
4. Max. workpiece weight: 12000 kg;
5. Spindle power/speed: 45/55 kW @ 200 rpm;
6. Spindle torque: 20800 Nm;
7. ATC tool magazine: 12T;
8. C-axis (CF-axis) – milling function;
9. Machine weight: 26000 kg
High coaxiality control for large components; nuclear components require non-damaging machining compliant with pressure standards.
Capable of machining corrosion-resistant materials (e.g., stainless steel, titanium alloys); suitable for dust-proof and explosion-proof workshop environments.
Same as ETL125ATC
Same as ETL125ATC+C standard configuration
Same as ETL125ATC optional configuration
1. Table diameter: 1800 mm;
2. Max. turning diameter: Φ2000 mm;
3. Max. turning height: 1400 mm;
4. Max. workpiece weight: 12000 kg;
5. Spindle power/speed: 45/55 kW @ 200 rpm;
6. Spindle torque: 20800 Nm;
7. ATC tool magazine: 16T;
8. Machine weight: 27000 kg
Includes secondary milling spindle
High coaxiality control for large components; nuclear components require non-damaging machining compliant with pressure standards.
Capable of machining corrosion-resistant materials (e.g., stainless steel, titanium alloys); suitable for dust-proof and explosion-proof workshop environments.
