1. General Machinery Industry: Flange, gear blank, belt pulley, coupling, motor end cover, bearing seat
2. Engineering & Mining Machinery: Excavator hub, track wheel, hydraulic cylinder bottom, crusher rotor body, wear-resistant bushing
3. Automobile & Rail Transit: Automobile hub, aluminum hub, brake drum, brake disc, flywheel, high-speed rail brake disc, bogie flange, train wheel
4. Energy Equipment (Wind Power/Hydropower/Nuclear Power): Wind power flange, water turbine runner body, nuclear power head, sealing ring
5. Petrochemical & Explosion-proof Equipment: Rod joint, wellhead flange, valve body, explosion-proof motor end cover, sealing shaft sleeve
6. Aerospace & Lightweight Equipment: Aircraft landing gear hub, engine turbine disk blank, casing, carbon fiber flange/bushing
7. Mould Manufacturing: Plastic mould core/cavity, bottle mould, tire mould pattern ring, die casting mould core
1. FANUC 0i-TF CNC System;
2. Worktable - Faceplate + 4 sets of single-acting powerful jaws;
3. Spindle 4-speed stepless gear box;
4. Hydraulic system;
5. Automatic lubrication system;
6. Double square ram: P1 tool rest, P2 tool rest / Hydraulic servo vertical turret 4T/5T/6T
1. SIEMENS 828D / GSK988TA CNC System;
2. Hydraulic servo vertical turret 4T/5T/6T;
3. Cooling system;
4. External protective sheet metal;
5. Grinding function;
6. Paper tape filter;
7. Oil-water separator;
8. Tool detection system
1. Worktable surface diameter: 2250mm;
2. Max machining diameter: Φ2500mm;
3. Max machining height: 1.4/1.6/2.0/2.5m;
4. Max workpiece weight: 10/20T;
5. Spindle speed: 2~63rpm (4-speed stepless);
6. Spindle torque: 63KNm;
7. Double square ram: 240×240mm ; 240×240mm
Heavy-duty model, suitable for machining large and heavy workpieces
Coaxiality control of oversize parts; Non-destructive machining for nuclear power parts, complying with pressure resistance standards
Machining of corrosion-resistant materials (stainless steel, titanium alloy); Meet the standards of dust-proof and explosion-proof workshop
Same as GTL2500
Same as the standard configuration of GTL2500
Same as the optional configuration of GTL2500
1. Worktable surface diameter: 2800mm;
2. Max machining diameter: Φ3200mm;
3. Max machining height: 1.6/2.0/2.5m;
4. Max workpiece weight: 10/20T;
5. Spindle speed: 2~63rpm (4-speed stepless);
6. Spindle torque: 63KNm;
7. Double square ram: 240×240mm ; 240×240mm
Heavy-duty model, suitable for machining large and heavy workpieces
Coaxiality control of oversize parts; Non-destructive machining for nuclear power parts, complying with pressure resistance standards
Machining of corrosion-resistant materials (stainless steel, titanium alloy); Meet the standards of dust-proof and explosion-proof workshop
Same as GTL2500
Same as the standard configuration of GTL2500
Same as the optional configuration of GTL2500
1. Worktable surface diameter: 3200mm;
2. Max machining diameter: Φ4000mm;
3. Max machining height: 1.6/2.0/3.0m;
4. Max workpiece weight: 20/32T;
5. Spindle speed: 2~63rpm (4-speed stepless);
6. Spindle torque: 80KNm;
7. Double square ram: 260×260mm ; 260×260mm
Heavy-duty model, suitable for machining large and heavy workpieces
Coaxiality control of oversize parts; Non-destructive machining for nuclear power parts, complying with pressure resistance standards
Machining of corrosion-resistant materials (stainless steel, titanium alloy); Meet the standards of dust-proof and explosion-proof workshop
Same as GTL2500
Same as the standard configuration of GTL2500
Same as the optional configuration of GTL2500
1. Worktable surface diameter: 4000/4500mm;
2. Max machining diameter: Φ5000mm;
3. Max machining height: 2.0/3.0/4.0m;
4. Max workpiece weight: 40/65T;
5. Spindle speed: 0.4~40rpm (4-speed stepless);
6. Spindle torque: 100KNm;
7. Double square ram: 260×260mm ; 260×260mm
Heavy-duty model, suitable for machining large and heavy workpieces
Coaxiality control of oversize parts; Non-destructive machining for nuclear power parts, complying with pressure resistance standards
Machining of corrosion-resistant materials (stainless steel, titanium alloy); Meet the standards of dust-proof and explosion-proof workshop
Same as GTL2500
Same as the standard configuration of GTL2500
Same as the optional configuration of GTL2500
1. Worktable surface diameter: 4500/5000mm;
2. Max machining diameter: Φ6300mm;
3. Max machining height: 2.0/3.0/4.0m;
4. Max workpiece weight: 65/80T;
5. Spindle speed: 0.4~40rpm (4-speed stepless);
6. Spindle torque: 100KNm;
7. Double square ram: 280×280mm ; 280×280mm
Heavy-duty model, suitable for machining large and heavy workpieces
Coaxiality control of oversize parts; Non-destructive machining for nuclear power parts, complying with pressure resistance standards
Machining of corrosion-resistant materials (stainless steel, titanium alloy); Meet the standards of dust-proof and explosion-proof workshop
Same as GTL2500
Same as the standard configuration of GTL2500
Same as the optional configuration of GTL2500
1. Worktable surface diameter: 7200mm;
2. Max machining diameter: Φ8000mm;
3. Max machining height: 2.0/3.0/4.0/5.0m;
4. Max workpiece weight: 80/120T;
5. Spindle speed: 0.4~20rpm (4-speed stepless);
6. Spindle torque: 500KNm;
7. Double square ram: 280×280mm ; 280×280mm
Heavy-duty model, suitable for machining large and heavy workpieces
Coaxiality control of oversize parts; Non-destructive machining for nuclear power parts, complying with pressure resistance standards
Machining of corrosion-resistant materials (stainless steel, titanium alloy); Meet the standards of dust-proof and explosion-proof workshop
Same as GTL2500
Same as the standard configuration of GTL2500
Same as the optional configuration of GTL2500
1. Worktable surface diameter: 8500mm;
2. Max machining diameter: Φ10000mm;
3. Max machining height: 2.0/3.0/4.0/5.0m;
4. Max workpiece weight: 120/150/200T;
5. Spindle speed: 0.4~20rpm (4-speed stepless);
6. Spindle torque: 500KNm;
7. Double square ram: 320×320mm ; 320×320mm
Heavy-duty model, suitable for machining large and heavy workpieces
Coaxiality control of oversize parts; Non-destructive machining for nuclear power parts, complying with pressure resistance standards
Machining of corrosion-resistant materials (stainless steel, titanium alloy); Meet the standards of dust-proof and explosion-proof workshop
